Automatic Sleeve Immersion Tin Machine - Cable Process Strip Tin-DIP
- Stripping Brush Wire Twisting Wire Stripping Machine
- One-stop station completion
- HDMI wire harness1185wire car audio wiremedicalwireharness.
- Stripping-breaking braid-braiding erection-twisting thread- Features braiding cut to the root-pushing down and braiding-removing black skin-open core thread ...
- Model Number
- BR-10
- Certification
- CE
- Origin
- Mainland China
- Condition
- New
- Type
- Horizontal
Reply within 24 hours · 12-month warranty
Automatic Sleeve Immersion Tin Machine Cable Process Machine Strip Tin-DIP and Copper Wrap
This machine is Applicable wire USB3.0/4.0 series HDMI wire harness1185wire car audio wiremedicalwireharness. Main function : Stripping-breaking braid-braiding erection-twisting thread-
Features braiding cut to the root-pushing down and braiding-removing
black skin-open core thread
Feature:.
* Stripping Brush Wire Twisting Wire Stripping Machine
Peeling, breaking up weaving,braiding upright,twisting
pushing down weavingremoving aluminum foil
*One-stop station completion
The station is completed in one stopthe operation is simple and it saves 4-6 workers compared with the original operation method
Product Description
| Model | BR-10 |
|---|---|
| Power supply | AC220V50/60HZ |
| Applicable wire diameter | 2.5-5mm |
| Stripping length | 10---45mm |
| Peeling method | Rotary peeling |
| Twisting method | Digital operation(electric motor drive) |
| Display method | Chinese and English touch screen LCD display |
| Transmission structure | Slide rail,reducerchain |
| Air pressure | 0.6MP--0.8MP |
| Capacity | 1300--1400PCS/H |
| Weight | 168 kg |
| Dimension | L1200*W750*H1350 |
| Certification | CE |
|---|---|
| Condition | New |
| Model Number | BR-10 |
| Origin | Mainland China |
| Type | Horizontal |
