Automatic Wire Twisting & Stripping Machine SWT508-NX2
- Wire Stripping Machine made by our factory is suitable for cutting, head-stripping, tail-stripping and middle-stripping of single –strand, multi-strand and s...
- With rollers lifting function when stripping Wire Head,SWT508-HT2 is suitable for stripping sheath wire especially for sheath wire of long Wire Head and Wire...
- L (L = Cutting Length) Stripping Length: Head 0.
- Model
- SWT508NX2 Automatic Wire Stripping Peeling Cutting Machine
- Model Number
- SWT508NX2 wire stripping machine
- Certification
- CE;FCC;RoHS
- Application
- Computer
- Origin
- Mainland China
- Type
- Male to Female
Reply within 24 hours · 12-month warranty
SWT508-NX2 Computer Automatic Wire Strip Twisting Peeling Stripping Cutting Twister Single Double Cable Stripper for 0.1-4.5mm2
P.S: The wire collecting board and protect cover is not include. if you need add. please contact seller.
Introduction
1). SWT Series Full-automatic Computer Wire Stripping Machine made by our factory is suitable for cutting, head-stripping, tail-stripping and middle-stripping of single –strand, multi-strand and sheath wire.
2). SWT508-NX2 is suitable for stripping and twisting super short wires with shortest wire of 28-30mm;
3). With rollers lifting function when stripping Wire Head,SWT508-HT2 is suitable for stripping sheath wire especially for sheath wire of long Wire Head and Wire Tail.
Power: 450W
Voltage: 220V/110V
Mode of Display: LCD Liquid Crystal Display Screen in English and Chinese
Cutting Length: 0.1mm – 100000mm
Cutting Tolerance: ≤0.002×L (L = Cutting Length)
Stripping Length: Head 0.1 – 35mm, End 0.1-20mm
Twisting Length: Head 0.1 –25mm,Tail 0.1-15mm
Twisting super short wires: 28-30mm
Cutting Cross-sectional Area of Wire Core:
Single: 0.1-4.5mm2
Double: 0.1-2.5mm2
Maximum Diameter of Conduit Pipe: ￠6
Middle-stripping: 13 places of stripping
Knife Material: High-quality Tungsten Steel
Stripping Speed: 4000 – 10000 pcs/h
Mode of Driving: Four-wheeled Drive (Silent hybrid stepping motor, each step 0.1mm forward)
Adjusting Speed: 0 Slowest, 9 Fastest
| Application | Computer |
|---|---|
| Certification | CE;FCC;RoHS |
| is_customized | Yes |
| Model | SWT508NX2 Automatic Wire Stripping Peeling Cutting Machine |
| Model Number | SWT508NX2 wire stripping machine |
| Origin | Mainland China |
| Type | Male to Female |
